Description

Features

Exceptional HD sound with wideband technology
Up to 4 simultaneous external calls
Up to 5 DECT cordless handsets
Up to 5 VoIP accounts
1.8″ color display with intuitive user interface
10 hours talk time, 100 hours standby time
Integrated PoE （Class 1）
Desktop or wall mountable

Specification

Phone Features
> Up to 4 simultaneous calls
> Up to 5 handsets, Up to 5 VoIP accounts
> Handset select for receiving call
> Handset and Number select for making call
> Paging, Intercom, Auto answer
> Call hold, Call transfer
> Switching between calls
> 3-way conferencing
> Call waiting, Mute, DND
> Caller ID display, Redial
> Anonymous call, Anonymous call rejection
> Call forward (Always/Busy/No Answer)
> Speed dial, Voicemail, Silence
> Message Waiting Indication (MWI)
> Local Phonebook for up to 500 entries (store in the base)
> Remote Phonebook
> Phonebook search / import / export
> Call history (Outgoing/Missed/Accepted)
> Direct IP call without SIP proxy
> Reset to factory, Reboot
> Keypad lock, Emergency call
> Dial Plan, Music on hold
> Broadsoft Directory, BroadSoft Call Log
> Broadworks Feature Key Synchronization
Personalization
> 9 ringer melodies
> Screen Saver, Two kind of colour schemes
> Multiple languages
Management
> Auto-provision via FTP / TFTP / HTTP / HTTPS
> Auto-provision with PnP
> Configuration: browser / phone / auto-provision
> Trace package and system log export
Voice and Codecs Features
> Full-duplex speakerphone
> Receiver volume control: 5 steps
> Ringer volume control: 5 steps+off
> Multiple advisory tones
> Acoustic warning for low battery status
> DTMF
> Wideband codec: G.722
> Narrowband codec: G.711µ/A, G.723, G.726, G.729, iLBC
> VAD, CNG, AEC, PLC, AJB
Network Features
> SIP v1 (RFC2543), v2 (RFC3261)
> SNTP/NTP
> VLAN (802.1Q and 802.1P)
> 802.1x, LLDP, PPPoE
> STUN Client (NAT Traversal)
> UDP, TCP
> IP Assignment: Static/DHCP
Security
> Open VPN
> Transport Layer Security (TLS)
> HTTPS (server / client)
> SRTP (RFC3711)
> Digest authentication using MD5
> Secure configuration file via AES encryption
> Admin / Var / User 3-level configuration mode
Connectors
> CAT-iq2.0
> 1 x RJ45 10/100M Ethernet port
> Power over Ethernet (IEEE 802.3af)
> Headset jack (2.5 mm)
Physical Features
> Range: 50 meters indoor, 300 meters outdoor
> 10 hours talk time, 100 hours standby time
> 1.8’’ 128×160 pixels color display
> Desktop or wall mountable
> LCD backlit, Key backlit
> Energy-saving ECO mode/ECO Mode+
> 12 key numerical keypad, 5 navigation keys 2 softkeys, 6 function keys, 6 shortcut keys
> 3 LEDs on Base: 1 x power, 1 x Network, 1 x Call
> Base station: DC 5V / 600mA Output
> Charger: DC 5V / 600mA Output
> Phone size: 144mm x 50mm x 24mm
> Base station size: 153mm x 108mm x 45mm
> Operating humidity: 10 ~ 95%
> Operating temp: －10 ~ +50°C
Package Features
> 1 x Handset, 1 x Base Station, 1 x Belt Clip
2 x Rechargeable Battery,
1 x Charger Cradle, 2 x Power Adapter
1 x Ethernet Cable, 2 x Guide, 1 x CD-ROM
> Qty/CNT: 10pcs
> Giftbox size: 213mm*198mm*97mm
> Carton Meas: 495mm*400mm*219mm
> N.W: 7.3KG
> G.W: 7.9KG
